Signs Placed on Concrete Median Barriers

Report Number(s): Report No. : 0-6646-1

Description: Crashworthy hardware and placement guidelines for placement of signs or light poles mounted on top of barriers. Base Type: Other Signs Placed on Concrete Median Barriers

Test Level: 3

MASH Test Number: 3-11

Proprietary/Non-proprietary: Non-proprietary

Pass/Fail: Pass

Evaluation: Testing + Engineering Analysis

Sponsor: Texas Department of Transportation

Test Article Description

Mounting Height: 84"

Base Type: Frangible/Yielding

Number of Legs: 1

Support Type: Pipe

Support Size: 2-1/2" OD Schedule 80

Support Material: Steel

Sign Material: Aluminum

Sign Size: 48" x 72"
