REBLOC 120FA_6_SF

Description: Precast concrete elements. Each element is 6.0 m (236.2 in) long , 0.62 m (24.4 in) wide and 1.20 m (47.2 in) high. The elements are connected on-site utilizing steel couplings protruding from each element. Steel beams are situated at the element joints to make the barrier more rigid. The beams are placed in recesses at the bottom of each element. The first and the last element of the continuous installation length must be anchored to the asphalt surface using six screw bolts.

Test Level: 3

Eligibility Letter: B-363

System Type: Concrete to Concrete

MASH Test Number: 3-10, 3-11

Proprietary/Non-proprietary: Proprietary

Pass/Fail: Pass

Evaluation: Full-Scale Crash Testing

Sponsor: REBLOC GmbH

Test Article Description

Transition Type: n/a

Nested: n/a

Rubrail: No

Rubrail Nested: No

Height: 47.2"

Curb Present: No

Report(s):

B-363
