GUARDRAIL TO RIGID BARRIER TRANSITION ATTACHED TO BRIDGE OR CULVERT STRUCTURE

Report Number(s): 0-6954-R1

Description: The Guardrail to Rigid Barrier Transition Attached to Bridge or Culvert Structure installation was approximately 102 ft-103⁄4 inches long. It consisted of a 16-ft long reinforced concrete parapet and moment slab, a 27 ft-61⁄4 inch long W-beam to thrie-beam to parapet transition section that was anchored to the parapet, 50 ft of W-beam guardrail, and a Downstream Anchor Terminal (DAT)

Test Level: 3

System Type: Guardrail to Bridge Rail

MASH Test Number: 3-20,3-21

Proprietary/Non-proprietary: Non-proprietary

Pass/Fail: Pass

Evaluation: Full-Scale Crash Testing

Sponsor: Texas Department of Transportation
